How to Reduce Shrinkage in Injection Molding?

Injection molding is a widely used manufacturing process for producing various types of plastic products. Shrinkage is a common issue that occurs during this process, which can cause significant defects and affect the quality of the final product. Shrinkage refers to the reduction in size of the plastic part after it has been molded. In this article, we will discuss how to reduce shrinkage in injection molding.


Introduction to Shrinkage in Injection Molding


Shrinkage is a natural occurrence that happens when plastic cools down after being molded. The plastic material shrinks slightly due to the reduction in temperature, which can cause the plastic part to become smaller than its intended size. This can result in a variety of defects, including warping, sink marks, and dimensional inaccuracy.


Understanding the Causes of Shrinkage


Shrinkage can be caused by various factors, including material selection, mold design, processing conditions, and part geometry. Understanding these factors is essential to reduce shrinkage and ensure high-quality molded parts.


Material Selection


The type of plastic material used in injection molding can significantly affect the shrinkage rate. Some materials have a higher shrinkage rate than others, and this should be taken into consideration when selecting the material.


Mold Design


The mold design can also affect the shrinkage rate of the molded part. The mold should be designed to minimize the cooling time and ensure that the plastic material cools down uniformly. This can be achieved by adding cooling channels or using a hot runner system.


Processing Conditions


The processing conditions, such as the injection pressure, melt temperature, and cooling time, can also affect the shrinkage rate. The processing conditions should be optimized to ensure that the plastic material cools down uniformly and reduces the shrinkage rate.


Part Geometry


The geometry of the part can also affect the shrinkage rate. Parts with thin walls or complex geometries are more prone to shrinkage. The part geometry should be optimized to minimize the risk of shrinkage.


Techniques to Reduce Shrinkage


Reducing shrinkage in injection molding requires a combination of material selection, mold design, processing conditions, and part geometry optimization. Here are some techniques to reduce shrinkage:


Material Selection


Selecting a material with a lower shrinkage rate can help reduce the shrinkage of the molded part. Some materials, such as nylon and acetal, have a lower shrinkage rate than other materials.


Mold Design


Designing the mold with proper cooling channels or using a hot runner system can help reduce the cooling time and ensure that the plastic material cools down uniformly. This can help minimize the shrinkage rate.


Processing Conditions


Optimizing the processing conditions, such as the injection pressure, melt temperature, and cooling time, can help reduce the shrinkage rate. The processing conditions should be adjusted to ensure that the plastic material cools down uniformly and reduces the risk of shrinkage.


Part Geometry


Optimizing the part geometry can also help reduce shrinkage. Designing the part with thicker walls or simpler geometries can help minimize the shrinkage rate.


Reducing shrinkage in injection molding requires a combination of material selection, mold design, processing conditions, and part geometry optimization. By understanding the causes of shrinkage and implementing these techniques, manufacturers can produce high-quality molded parts with minimal defects and dimensional accuracy.


Jeward Mould is an adept company focused on plastic mold manufacturing to provide plastic injection molds for sale, with the ability to utilize a variety of mold technologies. Our expertise lies in Thin wall mould, Multi-shot molding, Large-part injection molding, and Gas assist molding. Click for more information.
